Dovetail And Modular Dovetail Fixtures

Dovetail fixture provide strong clamping force, rigidity and stability to allows users to machining most features in one set up

The dovetail fixture provides incomparable clamping power whilst exposing all 5 sides of a component, which allows users to machine most features in one operation.

Modular dovetail integrate 52 and 96 distance standard top tooling to expand the usability of the dovetail

Lightweight aerospace grade Aluminum
Locating pins to good repeatability
45°dovetail design to increase clamping force
Superior clamping strength, stability, and rigidity.
Compatible with 52 and 96 zero point system
Integrated stainless steel material, grinding process to ensure stability

Dovetail fixture specification

SilverCNC dovetail fixtures are currently available in 3 variants – YW12, YW25 and the YW50.

Each of the SilverCNC dovetail fixtures incorporate a precision location pin, which eliminates component-slide and allows for repeatable reloading of parts.

The locating pin ensures your part is positioned accurately

Dovetail YW12 specs

Dimension: 21*32*19mm
Dovetail depth: 2.54mm
Clamping range: 12-25mm
Material: stainless steel
Max. torque:8Nm
Weight/Kg: 0.15KG

Dovetail YW25 specs

Dimension: 38*38*27mm
Dovetail depth: 2.54mm
Clamping range: 25-70mm
Material: stainless steel
Max. torque: 10Nm
Weight/Kg: 0.25KG

Dovetail YW50 specs

Dimension: 50*50*38mm
Dovetail depth: 2.54mm
Clamping range: above 50mm
Material: stainless steel
Max. torque: 40Nm
Weight/Kg: 0.65KG

Modular Dovetail Fixtures

1, Mdular dovetail fixture designed to achieve quick change the dovetail when integrate with various zero point system or workholding.
2, SilverCNC offer 6 modular dovetail models that can be quickly interchanged with the 52 and 96 zero point base plates respectively.
3, Each modular dovetail fixture include 4 pcs studs for free.
